RK3566 high-performance AI processor, Neural Network Processor NPU, Android 11.0 operating
system, RK3566 is based on a quad-core A55 architecture using a new 22nm process of ARM
v8.2-A, featuring a quad-core 64-bit CPU with a high frequency of up to 1.8GHz, providing strong
general computing performance. The GPU uses ARM G52 2EE, with an internal AI Neural Network
Processor NPU that has a computing performance of up to 1.0 TOPS, supporting various AI development
tools and interfaces. It supports LVDS interface 1080P output, eDP and MiPi display interface output, HDMI-4K
output, and supports Ethernet, WiFi, USB expansion/serial port expansion/IO expansion/I2C expansion.
